How to Read Electronic Component Codes: A Beginner’s Guide

- July 10, 2025

Understanding electronic components is the first step toward building circuits, repairing devices, or diving into electronics as a hobby or profession. But when you look closely at those tiny parts — resistors, capacitors, and ICs — you'll see they’re covered in stripes, numbers, and codes.

In this guide, we’ll break down the mystery and teach you how to decode these components like a pro.

1. Resistor Color Codes – What Do the Stripes Mean?

Resistors are one of the most common components in any circuit. Instead of printing numbers on them, they use colored bands to indicate their resistance value in ohms (Ω).

How It Works:

Most resistors have 4, 5, or 6 color bands. Each color represents a number based on this table:

Color	Digit
Black	0
Brown	1
Red	2
Orange	3
Yellow	4
Green	5
Blue	6
Violet	7
Gray	8
White	9

Example: A 4-Band Resistor

Let’s say you see Brown–Black–Red–Gold:

Brown (1)
Black (0)
Red (×100 multiplier)
Gold (±5% tolerance)

This means:

10 × 100 = 1,000 ohms (1kΩ) with ±5% tolerance.

Tip: Use the mnemonic:

BB ROY of Great Britain Very Good Wife (Black, Brown, Red, Orange, Yellow, Green, Blue, Violet, Gray, White)

2. Capacitor Codes – What Does “104” Mean?

Unlike resistors, capacitors often have numeric codes printed directly on them.

One common example is: 104

How to Read It:

First 2 digits = base value → 10
Third digit = number of zeros → 10,000
Units = picofarads (pF)

So:

10 × 10,000 = 100,000 pF= 0.1 µF (microfarads)

Common Codes to Know:

Code	Value
102	1,000 pF (0.001 µF)
103	10,000 pF (0.01 µF)
104	100,000 pF (0.1 µF)
105	1,000,000 pF (1 µF)

Capacitors may also list tolerance letters (like "J" for ±5%) or voltage ratings.

3. IC Part Numbers – What’s Printed on That Chip?

Integrated Circuits (ICs) are the “brains” of many electronics. Each chip usually has a part number printed on the top, which tells you what the chip does.

Common Examples:

555 – Timer IC used in oscillators and delay circuits
74LS00 – Logic gate IC (Quad 2-input NAND gates)
LM317 – Adjustable voltage regulator

How to Decode:

The code is often a standard part number registered by the manufacturer. You can Google the part number (e.g., “NE555 datasheet”) to see full specifications, pinouts, and applications.

Pro Tip:

ICs may also include manufacturer initials (e.g., "TI" for Texas Instruments) and production batch codes — focus on the main number like "LM358" or "CD4011."

Bonus: Online Tools & Tips

Need help decoding? Try these:

Resistor Color Code Calculators (available online and as apps)
Capacitor Code Converters
Datasheet websites like AllDatasheet or Octopart

Apps like ElectroDroid (Android) or EveryCircuit (iOS/Android) also make learning much easier.

Summary: Decode Like a Pro

Component	What to Look For	How to Decode
Resistor	Colored bands	Use color chart to calculate resistance
Capacitor	Number code (e.g., 104)	Convert to picofarads or microfarads
IC	Printed part number	Search for datasheet to identify function

Conclusion

Electronics might seem overwhelming at first, but once you know how to read the language of components, it all starts to make sense. Whether you're building a circuit from scratch, repairing a gadget, or just learning out of curiosity — decoding component codes is a skill that opens the door to a whole new world of tech exploration.

So grab a multimeter, a soldering iron (if you're ready), and start decoding — one component at a time.

To know more, watch our video : https://www.youtube.com/shorts/h76BY-cNQ6o
